Disconnector 4 Poles 40A - LS

€18.69 Tax included

€15.45 tax excl.

4-pole, 40A load break switch . Din rail mounting, 4 modules wide. BKD series.

Reference: BKD 4P 40A

Electrical diagram disconnector 4 poles

Brand LS Electric


Representative image for illustrative purposes, the supplied article will correspond to the indicated specifications.

No queries yet, leave the first!


4-pole, 40A load break switch for disconnecting voltage from an electrical installation or machine. 70mm wide modular design for DIN rail mounting.

Characteristic:

  • Manufacturer: LS (LG)
  • Reference: BKD 4P 40A
  • Number of poles: 4
  • Rated voltage: 240/415Vac 50/60Hz
  • Rated current: 40A
  • Electrical life: 1500 operations
  • Mechanical life: 10,000 operations
  • Mounting: 35mm DIN rail
  • Width: 17.5mm per pole. 70mm
  • Standard: IEC60947-3

Attention: This component should not be confused with a magnetothermic , they are two different elements.






Material for professional use, it must be installed by qualified personnel in compliance with the regulations in force at the place of installation.
