Change over switch , electrical circuit selector, 3 poles 32A. The operation is carried out by means of a front lever, with 3 maintained positions (I-0-II). Three output contacts.
Technical characteristics:
- Manufacturer/Supplier: Tracon
- Reference: SVK3-32
- Number of poles: 3
- Control type: 3-position lever
- Contact type: 3 C/O
- Rated voltage: 230Vac 50/60Hz
- Rated current: 32A
- Rated insulation voltage (Ui): 690Vac
- Rated impulse withstand voltage (Uimp): 6kV
- Electrical life: > 10000 cycles
- Mechanical life: > 30000 cycles
- Operating temperature: -25ºC...+55ºC
- Protection grade: IP20
- Conductor section: 3 - 16mm²
- Allows the use of pin-type connection combs
- Sealable in position 0-I-II
- Regulations: EN 60947-3, EN 60669-1
Dimensions:
Material for professional use, it must be installed by qualified personnel, respecting the regulations in force at the installation site.
