Needle roller bearings with single row needle roller and cage assemblies without inner ring NK 110 30 TN 110x130x30 ISB - ADAJUS
Needle roller bearings with single row needle roller and cage assemblies without inner ring NK 110 30 TN 110x130x30 ISB - ADAJUS

Needle roller bearings NK 110/30 110x130x30 - ISB

€149.02 Tax included

€123.16 tax excl.

Single row needle roller bearings (drawn cup needle roller bearing) with ribs and without inner ring, dimensions 110x130x30mm. NK drawn cup needle roller bearings without inner race, drawn cup needle roller and cage assembly and outer ring form a self-retaining unit. This bearing is used when the shaft can be hardened and ground.

Part No.: NK 110/30

Logotipo Descripción generada automáticamente

Representative picture for illustrative purposes, the item supplied will correspond to the specifications shown

No queries yet, leave the first!
Privacy
Shipments
Returns


The non-detachable drawn cup needle roller bearings, needle roller and cage assembly and outer ring form a self-retaining unit. These bearings are suitable where limited radial construction space is available.

Drawn cup needle roller bearings are used for bearings, when the shaft can be hardened and ground.

Dimensions: Ø110xØ130x30mm.

For other references or dimensions please consult.


Diagrama, Texto, Esquemático Descripción generada automáticamente
Diagrama Descripción generada automáticamente

Characteristics:

  • Material: hardened steel.
  • Dimensions
    • Fw: 110 mm
    • D: 130 mm
    • C: 30 mm
  • Load coefficients (N)
    • Dynamic C: 96000
    • Static dynamic C0: 209000
  • Maximum rpm: 3900

Material for professional use, to be installed in compliance with the regulations in force at the place of installation.

For further information you can download the technical data sheet by clicking on the "Attachments" tab
