630VA 230/400Vac IP-00 single-phase autotransformer
630VA 230/400Vac IP-00 single-phase autotransformer

Single-phase autotransformer 630VA 230/400Vac IP-00

€60.90 Tax included

€50.33 tax excl.

Single-phase reversible autotransformer of 630VA, allows voltage adaptation between 230 and 400Vac.

It allows to adapt the voltage in small machinery and cabinets for automatisms in an economic way.

Reference: AT2 630

Esquema eléctrico de autotransformador monofásico
Representative image for illustrative purposes, the item supplied will correspond to the specifications indicated.

No queries yet, leave the first!


Single-phase autotransformer for voltage change, reversible, intended for voltage change. They are indicated when it is required to adapt the voltage from 230 to 400v / 400 to 230Vac, in an economic way, without galvanic separation. Their usual field of application is the use in small machinery and automatisms.

Manufactured with low loss magnetic sheet and with wire windings of copper, providing high performance.

Technical characteristics:

  • Reference: AT2-630
  • Transformer ratio: 230/400Vac
  • Power: 630VA.
  • Frequency: 50/60Hz.
  • Windings: Thermal class N 200ºC.
  • Test voltage: 3KV between ground.
  • Insulation: Thermal class F 155ºC and H 180ºC.
  • Protection: IP-00.
  • Ambient temperature: TA=25ºC.
  • Cooling: ANAN (Natural air).
  • Certificate: UNE-EN 61558



The autotransformer is supplied without any type of overload protection, it is mandatory to install them to avoid overloading the transformer. The power and current indicated are apparent, the active current provided by the transformer will depend on the power factor of the connected load.
Material for professional use, install in compliance with the regulations in force at the place of installation.
