Frequency converter single-phase 1.5kW vector VFC3 Series

€249.08 Tax included

€205.85 tax excl.

Frequency converter single-phase 230V 1.5kW (2CV) vector. With built-in RFI filter and fixed programming panel (non-removable).

The single-phase frequency converters allow the control and speed variation of standard three-phase motors from a single-phase supply network.


Part No.: VFC3-021-1.5K


Representative image for illustrative purposes, the item supplied will correspond to the specifications shown.

No queries yet, leave the first!


Frequency converter single-phase 230V 1.5kW (2CV) vector, with built-in RFI filter and fixed programming panel (not removable). The single-phase frequency converters (frequency inverters) allow the control and speed variation of standard three-phase motors from a single-phase supply network. They are only suitable for connection to AC motors.

This model of frequency converter incorporates RFI filter to avoid electromagnetic interference that could occur with other electronic components. On its front panel, it incorporates all the necessary controls for motor control and a potentiometer for speed regulation. This inverter model can be controlled from potentiometer and external push buttons.


The VFC3 series of frequency converters incorporates:

  • Integrated programming panel (not removable) with setting dial
  • 15 programmable speeds with input activation
  • PID control
  • RS485 communication
  • RFI filter included
  • DIN rail mounting as standard



Technical characteristics:

  • Manufacturer: SITRONIC
  • Part number: VFC3-021-1.5K
  • Maximum motor power: 1.5kW (2CV)
  • Rated Voltage/Frequency: Single-phase 200 - 240Vac 50/60Hz
  • Maximum Allowable Range: Single Phase 170 - 264Vac
  • Frequency tolerance: ± 5% (47 - 63Hz)
  • Maximum output voltage: 3-phase 200 - 240Vac
  • PWM Frequency: 1 - 15kHz
  • Rated output current: 8A
  • Overload capability: 150% - 60 seconds 200% - 1 second



Control characteristics
  • V/F control, open-loop vector control
  • Output frequency 0 to 650Hz
  • Modbus communication (RS485)
  • Built-in braking module
  • Compact design
  • Ventilation type: Forced
  • Ambient temperature: -10ºC to 50ºC
  • Degree of protection: IP20
  • Weight: 1.38kg
  • Dimensions (H x W x D): 147 x 136 x 128mm



NOTE: A magnetothermic must be installed at the input of the for power line protection (refer to the instruction manual for the appropriate magnetothermic size for each drive model). Slow fuses can also be installed.




For further information, you can download the data sheet by clicking on the "Attachments" tab.

This equipment is for professional use and must be installed by qualified personnel in compliance with the regulations in force at the place of installation
