€5.52 Tax included

€4.56 tax excl.

Base for relay with 1 contact, flat pin and 5 pins for SCHNEIDER RSB1A120XX relays . Mounting on 35mm DIN rail or panel mounting.

Reference: RSZE1S35M






Representative image for illustrative purposes, the supplied article will correspond to the indicated specifications.

No queries yet, leave the first!


Base for 1 contact relay , for mounting on DIN rail by means of clip or mounting on panel by means of screw. Flat Pin Shape Connection by screw connector.


Compatible with SCHNEIDER RBS-HARMONY series relays with 1 contact RSB1A120XX


Technical characteristics:

  • Manufacturer: SCHNEIDER
  • Reference: RSZE1S35M
  • RSB SERIES - HARMONY
  • Holding capacity: 1 contact
  • Conventional thermal current: 12A
  • Rated operating voltage: < 250V
  • Ambient temperature: -25 to +85 o C
  • Degree of protection: IP20 conforming to EN/IEC 60529
  • Dielectric voltage: 2500V
  • screw connection
  • Compatibility of SCHNEIDER RSB-HARMONY series relays with 1 contact



Dimensions (mm/in):



NOTE : The base is supplied without any of the accessories (1), (2), (3) indicated in the diagram above





NOTE: For DC input, A1 has to be +, otherwise it will cause a short circuit from the protection module.




For more information, you can download the technical sheet by clicking on the "Annexes" tab.

Material for professional use, it must be installed by qualified personnel in compliance with the regulations in force at the place of installation.
