Thermal relay regulation 28 to 40A - LS

€42.57 Tax included

€35.18 tax excl.

Three-phase thermal relay for overload protection of electric motors. The regulation of the thermal relay is between 28 to 40 A.

Reference: MT-63 34A 3H

Esquema electrico rele termico

Logotipo LS Industrial systems

No queries yet, leave the first!


Three-phase thermal relay for protection of electric motors against overloads. The thermal relay has 2 independent auxiliary contacts (1 open and one closed). The reset can be selected to occur automatically or manually by pushbutton located on the body of the thermal relay. It has ambient temperature compensation.

The thermal relay is designed to be coupled directly to the output of a contactor, it can also be attached to a DIN rail using the available adapter.

Thermal relay features:

  • Manufacturer: LG - LS.
  • Reference: MT-63 34A 3H
  • Regulation range: 28 to 40A.
  • Rated voltage Ue: 690V.
  • Insulation voltage: 690V.
  • Maximum Uimp peak voltage: 6kV.
  • Kind of shot: 10.
  • Compatible with MC-50 and MC-65A contactors.
  • Ambient temperature compensation between -5 and 40oC.
  • Weight: 0.33 Kg.
  • Dimensions: 55x81x100mm.
