MCB circuit breaker 2 poles 100A 10kA - Hyundai Electric
MCB circuit breaker 2 poles 100A 10kA - Hyundai Electric

MCB circuit breaker 2 poles 100A 10kA - Hyundai Electric

€25.42 Tax included

€21.01 tax excl.

MCB circuit breaker 2 poles 100A curve C, for protection against short circuits and overloads in industrial and tertiary applications. Hyundai brand. With a cutting power assigned according to IEC/EN60898 of 10000A (10kA), active protection of the poles with individual status indication of each of the poles.

Reference: HGD100S-2P100C.

Esquema eléctrico margnetotérmico 2 polos

No queries yet, leave the first!


MCB circuit breaker 2 poles 100A 10kA curve "C", for protection against short circuits and overloads in single-phase or biphasic installations. With an assigned cutting power of 10kA, active protection of the poles with status indication. Manufactured in fireproof thermoplastic material and in accordance with IEC/EN60947-2 reference regulations.

As main features of this product range we can review:

  • Accurate shooting lever performance.
  • Easy removal of DIN rail.
  • 13 plates in the extinguishing chamber for effective arc cooling.
  • Free firing mechanism. The switch fires even if maintenance is forced in the on position (ON).
  • Visual status indication, Red-ON, Green-OFF.
  • Supports mounting a large number of accessories.

Main features of MCB circuit breaker:

  • Manufacturer/Supplier: Hyundai Electric.
  • Manufacturer's Reference: HGD100S-2P100C.
  • Nominal MCB circuit breaker intensity (In): 100A.
  • Number of poles: 2 (2x100A).
  • Step: 3 modules.
  • Cutting power (Icn): 10000A (10kA) (Ics-75% icn).
  • Maximum operating voltage (Eu): 240/415Vac, 50/60Hz.
  • Characteristic curve: C.
  • Assigned insulation voltage (Ui): 690Vac.
  • Rated pulse resistance voltage (Uimp): 4 KV.
  • Dielectric resistance: 2.5kV.
  • Protection: IP20.
  • Enduring: ≥10000/20000.
  • Operating temperature: -5oC... +55oC.
  • Humidity: 95% RH.
  • Energy limitation class: Class 3.
  • Regulations: EC; IEC60947-2 industrial application (type H), IEC60898-1 residential application.
  • Terminal type: Screw tightening jaw.
  • Maximum terminal capacity: 50mm2.
  • Maximum tightening torque: 2.5 Nm.
  • Weight: 0.300 Kg.
  • Dimensions (mm): 81x74.5x79.5.
  • Mounting position: Vertical/Horizontal.
  • Housing and cover material: Ignifugo molded thermoplastic.
  • Supports mounting of auxiliary elements: YES.

Dimensiones magnetotermicos HGD 125
