160VA ultra-isolation IP-20 monophasic transformer
160VA ultra-isolation IP-20 monophasic transformer
160VA ultra-isolation IP-20 monophasic transformer
160VA ultra-isolation IP-20 monophasic transformer

Transformer 160VA 400/230Vac ultra-isolation IP-20

€64.94 Tax included

€53.67 tax excl.

160VA primary 400Vac secondary 230Vac single-phase ultra-isolation transformer,intended for circuit power supply where galvanic separation of follow-up and filtering of disturbances is required.

Manufactured in resin encapsulator, protection grade IP-20.

Reference: TRIA160-400-230

esquema transformador monofásico con pantalla 400-230



No queries yet, leave the first!


160VA ultra-insulated single-phase transformer,for control and manoeuvre in electrical circuits where galvanic separation of safety and leak filtering is required. They are manufactured at various primary and secondary stresses.

Ultra-insulated transformer with pharadic kick. Separation of primary and secondary circuits from a safety electrostatic display that filters and grounds unwanted signals and disturbances. The degree of leaking will depend directly on the quality of the grounding of the installation.

Manufactured with resin encapsulation that provides an IP-20 degree of protection.

Technical characteristics of the transformer:


  • Reference: TRIA160-400-230
  • Available primary/secondary voltages: 400/230Vac
  • Transformer power: 160 VA.
  • Windings: Thermal class N 200oC.
  • Insulators: Thermal class B 130oC.
  • Frequency: 50/60 Hz.
  • Protection: IP-20.
  • Transformer test voltage:
    • 5 KV between windings.
    • 2.5 KV between windings and dough.
  • Ambient temperature: Tao 25oC.
  • Transformer encapsulation: Self-extinguishing resin.
  • Transformer mounting: using screws.
  • Certificate: UNE-EN61558

Indicaciones de medicas transformadores monofasicos en resina

Table dimensiones transformadores monofasicos TRIA

Esquema electrico transformador separador con triple pantalla
